AKYAPAK AHS 12/04

The AHS features a 4 roll design that is arranged in such a way so that the 4 rollers work in tandem to ensure the plate is rolled evenly and without distortion. This innovative design provides an even pressure distribution across the plate, ensuring consistent rolling and high-quality results. The most impressive feature of the AHS, is its ability to achieve a full cylinder with just one pass. The lower roll allows for pre-bending and bending of material, so this saves both time and additional resources. Paired with Akyapak’s high-technology digital display, the AHS is incredibly easy to operate and features programmable settings that allow for the precise repetition of complex bending patterns and curves, making it ideal for high-volume production runs. The hydraulic system also provides precise control over the movement of the rolls, which is crucial when dealing with heavy and large plates. Working Length 4 ft. Max. Thickness 5/16 in. Pre-Bending Thickness 1/4 in. Top Roll Dia. 5.5 inn Bottom Roll Dia. 5.5 in Side Roll Dia. 4.7 in Motor Power 3 hp Length 12.0 ft. Height 3.4 ft. Width 3.7 ft. Weight 4,500 lbs.
